BMW 9395 E36 MS3Pro Plug and Play

Description

BMW 9395 E36 MS3Pro Plug and Play Standalone Engine Management System

Replace your “413” DME with a tunable racing ECU! Allows tuning your BMW 9395 E36 with a laptop to handle any mods you can throw at these engines!

BMW 9395 E36 MS3Pro Plug and Play fits the following applications (Confirmed for US market vehicles)

1993-1995 BMW 325 with M50 motor and manual transmission
1995 BMW M3 with S50 motor and manual transmission
1993-1995 BMW 525 with M50 motor and manual transmission
European market M3 compatibility is not confirmed at this point. Does not fit the earlier M50 non VANOS applications.

BMW 9395 E36 MS3Pro Plug and Play Features:

Fully Plug and Play Installation – No wiring required for basic functionality.
Average install time is under 1 hour!
Base map is pre-loaded to help your engine start on the first turn of the key
Real time tuning and data logging with a laptop connection
8 GB internal data logging with built in SD card
Supports most aftermarket wideband sensors
Fully Tunable Engine Control!

16×16 Fuel Tables allow high resolution tuning
16×16 Ignition Tables
Multiple Acceleration enrichment strategies
Closed Loop Idle Speed Control
Air Conditioner Control
6 sequential fuel injector channels with individual trim tables
Onboard peak and hold drivers support both high and low impedance injectors – No external ballast resistor is needed!
Allows removal of stock MAF sensor
VANOS control
Advanced Feature Set (Included!)

12×12 Air Fuel Ratio Target Tables for use with wide band O2 sensor for precise tuning and table trim.
Multiple traction control strategies
Built-in 3-step rev limiter / launch control with flat shift and burnout rev limiter
Time based timing / boost increase after launch
Real time barometric correction
Internal 4-bar MAP sensor reads up to 44PSI of boost
Overboost protection
Closed loop boost control (Requires EBC solenoid kit)
CO2 based boost control
Set boost by RPM and throttle, ground speed, or gear
Rally style anti lag
Water injection control – on/off or variable
Knock sensor input with adjustable sensitivity, crank angle windowing, and more
Table switching input. Change fuel and spark maps on the fly for different fuels, nitrous activation, etc.
Input for flex fuel sensor – switch between E85 and gasoline on the fly!
CANBus connector allows interconnection of other MegaSquirt-compatible devices for additional functions (EGT Input, Automatic Transmission Controller, Additional Sensors…..the possibilities are limitless!
What you get in the box:

BMW 9395 E36 MS3Pro Plug and Play ECU
RS232 tuning cable
Tuning Software and Documentation on USB memory stick with three base maps included
Stock M50
Stock S50
Modified S50 with upgraded cams and independent throttle body intake
6′ Vacuum Hose for MAP Signal and ‘T’ fitting
ECU mounting brackets (Note – currently these are in production, and will be shipped separately once they are ready)
Registered version of TunerStudio and MegaLog viewer included
Direct replacement for the following DME part numbers:

0 261 200 413
0 261 203 506
If your ECU / DME has a different part number, please contact us to see if this is compatible.
